4*2*0.2 Linear Motor Cable Servo Motors and Drives Wire

Chengjia Cable is specially designed for long-term high-speed linear motors with super-flexural resistant linear motors cables. Linear motor cables with the highest requirements in terms of mechanical, chemical and thermal properties. It must withstand high-speed acceleration and deceleration, tensile and compressive stress, and tens of millions of cycles of bending.

EMAIL

 50 million times Linear Motor Cable Servo Motors and Drives Wire

Brand: Chengjia

Color: black (other colors can be customized)

Features

Linear motor, also called linear motor, is a transmission device that directly converts electrical energy into linear motion mechanical energy without any intermediate conversion mechanism. The main application and automation control system are as long-term continuous-running drive motors and devices that need to provide huge linear motion energy in a short time and a short distance.

Chengjia Cable is specially designed for long-term high-speed linear motors with super-flexural resistant linear motor cable servo motors and drives wire. Linear motor cables have the highest requirements in terms of mechanical, chemical and thermal properties. It must withstand high-speed acceleration and deceleration, tensile and compressive stress, and tens of millions of cycles of bending. At the same time, it must be resistant to high temperature, metal splashing, oil, etc. and other chemicals. We Chengjia use specially modified insulation materials and outer covering materials, and the cables produced have high wear resistance and medium resistance, and always maintain high stability.

420.2 Linear Motor Cable Servo Motors and Drives Wire (3).jpg420.2 Linear Motor Cable Servo Motors and Drives Wire (4).jpg

1. The core wire has beautiful colors, distinct colors, abrasion resistance, oil resistance, and folding resistance

2. High-density shielding layer ≥90%, double-layer shielding, multi-layer structure

our stock.png

Specifications:

Number of coresConductor screenshot areaConductor structureInsulation materialShieldingSheath materialOuter diameterDrag chain times
 8 core0.2mm2 twisted pairMulti-layered Multi-layeredFluoroplastic ≥85% PUR6.4mm50 million times


Features Of Linear Motor Cable Servo Motors and Drives Wire:




Conductor: The optimized stranded conductor is highly flexible and resistant to bending, meeting the requirements of VDE0295 and IEC60228;


Insulation: Species thermoplastic material;


Shielding: Optimized shielding has high flexibility and meets EMC electromagnetic compatibility requirements;


Sheath: special thermoplastic material, resistant to oil, abrasion, halogen, hydrolysis and microorganisms;


Environmental protection: in line with the requirements of the EU RoHS directive. In line with the requirements of the EU REACH directive;


Temperature resistance: -40~80 degrees;


Minimum bending radius: 7.5*wire diameter, limit 4*wire diameter;


Service life: more than 50 million times of correct use;


Uses: Used in applications such as linear motors and other miniaturized long-term high-speed drag chains, bending and high-intensity sports
